Specification
Input Voltage Range: AC65V～AC500V；DC80V～700V
Input Current: 3x 0.3Amax
Output Voltage Range: 11.75~12.25Vdc;11~13.5Vdc
Standby Power:
Efficiency: 70%min（380VAC）
MTBF: 100,000hrs
Environmental Parameter
Operation Temp: -40℃ ~75℃
Storage Temp: -45℃~85℃
Humidity: 20%~90% (No Condensing)
Dimension
Size: 155mm*52.4mm*35mm(L*W*H)
Safety Standard
1) UL60065
2) EN60065
3) GB8898-2001)
